GECE GATE OPENER

 GECE Gate OPENER

Technical Specification

T24GECE800M

  1. Working Voltage : 220V/50 Hz AC/110V/60 Hz AC/380V/50 Hz AC
  2. Motor Power : 0.37 - 1.5 KW
  3. Starting Current : 3 A
  4. Motor Speed : 1400r/min
  5. Running Speed : 12m/min
  6. Applicable Door Weight : 800Kg
  7. Working Temperature : -40°C - +60°C
  8. Machine Net Weight : 38Kg
  9. Reserved Cable Installation : 1mm2 x 6-core (or 1.5 m2 x 2-core) Cable

Product Specification

Maximum Output Current : 10V
Fuse : AC220V 10 A
Remote Control Distance : Open Area > 30 Meters
Relative Humidity : < 60%

Special Functions

One Key Mode / 4 Key Mode
Easy Lock Functions on Remote
Auto Closing
Slow Stop Funtion
Ressistance Function
Closing Distance Learning Algorithm
Master Salve Function (Dual Motor Synchronous)
Motor Rotation Direction Convertion
GECE Swing Dimensions
